聚氯乙烯绝缘排线-UL2651
PVC Flat ribbon cable
产品描述 PRODUCT DEscriptION
额定电压Nominal Voltage:300Vac
温度范围Temperature Range:-40℃～+105℃
导体Conductor:14#～36#
绝缘体Insulation:PVC
颜色Colours:任一Any
适用范围APPLICATION
广泛应用于各种打印机打印头与主板之间的连接，绘图仪、扫描仪、复印机、来音响、液晶电器、传真机、各种影碟机等产品的信号传输及板板连接。
It is widely used in the connection between the print head of various printers and the main board, the signal transmission and board-board connection of plotters, scanners, copiers, audio, liquid crystal appliances, fax machines, various DVD players and other products.
| 导体 Conductor | 绝缘 Insulation | 芯数 Core P No. | 导体电阻 Ω/km | 耐电压 Dielectric Strength AC-V | |||
| 导体结构 No./mm | 绞合外径 mm | 厚度 Insulation Thickness mm | 外径 Overall Diameter mm | |||
| 14 | 41/0.254 | 1.87 | 0.23 | 2.35 | 2-150芯 Cores | 10 | 2000V |
| 16 | 26/0.254 | 1.49 | 0.23 | 1.95 | 15 | ||
| 18 | 34/0.18 | 1.21 | 0.23 | 1.67 | 23 | ||
| 20 | 20/0.18 | 0.92 | 0.23 | 1.38 | 39 | ||
| 22 | 17/0.16 | 0.76 | 0.23 | 1.22 | 59 | ||
| 24 | 11/0.16 | 0.61 | 0.23 | 1.07 | 90 | ||
| 26 | 7/0.16 | 0.48 | 0.23 | 0.94 | 142 | ||
| 28 | 7/0.12 | 0.36 | 0.23 | 0.82 | 253 | ||
| 30 | 7/0.1 | 0.30 | 0.23 | 0.76 | 364 | ||
| 32 | 7/0.08 | 0.24 | 0.23 | 0.70 | 568 | ||
| 34 | 7/0.06 | 0.18 | 0.23 | 0.64 | 1011 | ||
| 36 | 7/0.05 | 0.15 | 0.23 | 0.61 | 1455 | ||
